产品特点：

1.内置强大的内置Analog数字信号处理器，轻巧的机身，强大的功率输出;

2.处理器能准确的对音频信号进行路由、增益、相位、静音、参量均衡器、延时、分频、压缩和限制;

3.功放方面采用稳定高效的ClassD功放模块，ClassD功放模块的效率高达92%以上，这使功率放大器具有极高的效率和可靠性;

4.电源方面采用高效稳定的R-SMPS供电系统，集成有源功率因数校正电路(PFC)PFC使DSP系列功率放大器具有更高的可靠性和可控制性能够根据交流电压波形调整电流波形，适应全球范围的宽电压(90V-264V)运行，同时使得单个标准电流断路器能够承载更大的功率:

5.完善的保护系统，有效减少因使用不当造成的损坏，进一步提高机器可靠性;

6.高效稳定的ClassD功放模块，高效稳定的R-SMPS供电系统，高效的扬声器反电动势吸收系统;

7.独特的削峰限幅器和波纹消除网络;

8.极其轻便的整机重量和极小的空间点用率;

9.低音浑厚有力，中高频通透清晰、悦耳;

应用：

1.高功率密度和高音质要求扩声应用；

2. KTV/大中型酒吧/咖啡厅/休息室安装；

3.便携或者租赁行业PA系统应用。

Product Characteristic：

1.Built-in Analog digital signal processor,Lightweight body,strong power output;

2.Audio signals can be processed accurately by route,gain,phase,mute,parametricequalizer,delay,frequency division, compression and limitation

3.The power amplifier adopts a stable and efficient ClassD power amplifier module.The efficiency of theClassD power amplifier module is over 92%, which makes theDSP series power amplifiers have high efficiency and reliability,and also has extremely high power density.;

4.Power supply adopts high-efficiency and stable R-SMPS power supply system

5.The soft start LLC resonant SMPS module;

6.The active power factor correction (PFC), can be stable working in full voltage range (90-264V)

7.Perfect protection system to effectively reduce damage caused by improper use and further improve machine reliability;

8.The efficient speaker EMF absorption system;

9.The unique peak limiter and ripple cancellation network;

10.The low frequency powerful. depth is extremely low,mid high frequency with high transparent cleomponenet

11.The integration design of the power ampifier module and power supply module, more than 85% components with mechanical automation operation, to ensure the consistency of the product;

Applications：

1.The touring/portable audio performance;.

2.The KTV/ bar / Music Hall;

3.The stadium /arena.
